Image Map Example

Image Maps, an Example

This shows the coordinates or "hot-spots" mapped for the image.

circle (101,123) 42 imvh301.htm#SAMERICA

circle (56,46) 45 imvh301.htm#NAMERICA

circle (180,98) 41 imvh301.htm#AFRICA

circle (265,50) 47 imvh301.htm#ASIA

poly (218,10) (215,58) (138,49) (219,11) imvh301.htm#EUROPE

poly (346,68) (184,170) (347,170) imvh301.htm#OCEANIA

rect (4,3) (351,177) imvh301.htm#OCEANIA

default imvh301.htm

The image below was mapped using the MAPEDIT program found on the Web.

<A HREF="/CGI-BIN/IMAGEMAP/MAPK.MBR"><IMG SRC="IMVG300.GIF" ISMAP></A>

"/CGI-BIN/IMAGEMAP/" tells the location of the map files on the server.

"MAPK.MBR" specifies the name of the image map file on the server.

"IMG SRC" tells the browser which graphic file to use, imvg300.gif.

"ISMAP" tells the browser this is an image map.

Then some HTTP configuration to make it all work:

Map /CGI-BIN/IMAGEMAP/* /QSYS.LIB/QTCP.LIB/QTMHIMAG.PGM/QSYS.LIB/ITSOIC400.LIB/IMAGEMAP.FILE/*

Pass /QSYS.LIB/ITSOIC400.LIB/IMAGEMAP.FILE/*
